Product Description

Press brakes can be made to fit any bending requirement and size. These incredible machines are versatile and can work as a standalone unit or together in multiple arrangements, including integration with robotic cells or automated lines. Our press brakes have gained approval from Polo Tecnologico di Pordenone (Pordenone Technology Hub) for meeting the standards set by Industry 4.0 guidelines.

press brake dimensions

SuperCustom is a tailor-made solution that can be customized according to your unique needs such as open height, stroke, throat, and tool adapter height. It's like having a perfectly fitting suit for your product, particularly if your business involves deep boxes, tanks, and sizeable sinks. Embrace this bespoke technology and experience the seamless production process.

Product Models

Numerical order	Name		Value	Unit
1	Rated force		1600	KN
2	Platform Length		3200	mm
3	The strength of folded sheet material		450	N/mm2
4	Laryngeal opening depth		400	mm
5	slider travel		200	mm
6	The maximum opening height between the workbench surface and the slider		475	mm
7	slider travel speed	No load	60	mm/s
		Work	5
		Return	50
8	Main motor	model	Y32L-4 B35
		Power	11		KW
		Revolutions	1450		rpm
9	gear pumps	model	NT2-G20F
		Traffic	20		L/min
		pressure	32		MPa
10	Maximum working pressure of hydraulic system		25		MPa
11	Overall dimensions	Length	3550		mm
		Width	1740		mm
		Height	2450		mm
