Copper Granulator
The copper granulator is a machine used to crush waste copper wires to separate copper from plastic. Since the separated copper looks like rice grains, it is called a copper rice machine.
The domestic waste cable recycling industry is developing rapidly, but the copper wire obtained after the above technology is used to process waste cables can only be used as waste copper, and it still needs to go through smelting, electrolysis and other processes to become raw copper.
Copper rice machine is a relatively advanced technology for processing waste cables. The advanced copper rice machine has a good effect on processing waste cables. After a series of processing methods, the waste cables can obtain pure copper rice particles and plastics.
Product Parameters
|
Model |
Capacity(kg/h) |
Total power(Kw) |
Weight(kg) |
Dimension(m) |
|
NVOTD300 |
100-200 |
27 |
2800 |
3*2.1*2.8 |
|
NVOTD400 |
200-300 |
60 |
6600 |
6*3.5*3.2 |
|
NVOTD500 |
300-500 |
99 |
9000 |
10.1*9.6*5.7 |
|
NVOTD1000 |
800-1000 |
160 |
15000 |
21.5*9.5*5.7 |
Product Application
Thecopper granulator is a kind of environmental protection machinery. It is specially used to process various cables below Φ20mm such as automotive cables, communication cables, and various miscellaneous cables that are not suitable for processing by wire stripping machines. After crushing, it is separated by vibration screening, vibration separation, and water washing. It can completely separate copper and plastic, and achieve the purpose of comprehensive utilization, with high economic benefits. There is no dust and no secondary pollution. In addition, the equipment is an integral combined structure, which is easy to install and debug, and easy to transport. After the customer purchases it, it can be produced by connecting the power supply, and the performance is stable.
Product output effect
|
Scrap cables |
Finished product |
|
|
|
Copper |
Plastic |
Recycling Process
This is the process of 300kg~500kg per hour Scrap copper cable wire recycling machine.
Product Features
The crusher structure is different to the domestic manufacturer,the upper chamber is Arc-shaped which is more suitable for material feeding, the crushing chamber can be separated, so it's easy for blade maintenance;
The cutter adopts the special alloy steel from the material properties and heat treatment process is more suitable for cutting copper cable;
Our vibration panel is customized, the domestic market commonly use ordinary panel which have two disadvantages: a.fine wire will block panel, b. it will generate static electricity which will be sticky on panel mesh, it's very difficult to clean, these two factors will seriously affect the separation effect.
Dust removal is different.
