Scrap Ferrous And Non-Ferrous Baler

Uses of metal hydraulic baler: It is suitable for steelmaking plants, recycling and processing industries and non-ferrous and ferrous metal smelting industries. All kinds of metal scraps, steel shavings, scrap steel, scrap aluminum, scrap copper, etc. can be extruded into rectangular,...

Send Inquiry

Chat Now

Baler machine used clothes baling press machine, the function of the it is to bale the waste paper into blocks or briquettes. Packing into blocks, it is easy to transport and save transport cost and also save storage space.

The automatic baler machine adopts grade acceleration: when start then baling machine normally, it adopts three-stage acceleration, decelerates to the second level when it meets the resistance, and automatically slows down to the first grade when the scissors are cutting paper, and automatically recovers at full speed when the packing is completed.

_02

Specification

Model	Nominal pressure (ton)	Material box size	Baler size(mm)	Productivity (kgs/h)	Bale discharging mode	Motor (KW)	Machine weight (ton)
		(mm)
YD-630A	63	1000600500	200*200	500-750	Turn over	11	4.5
YD-1000	100	1000700500	250*250	750-1000	Turn over	11	5.5
			220*220
			200*200
YD-1000A	100	1100500500	200*200	750-1000	Front bale	11	5
YD-1300B	130	1200700550	300*300	1000-1800	Turn over	15	6
			250*250
YD-1300C	130	1200800550	300*300	1500-2000	Turn over	15	6.5
			250*250
YD-1350	135	1400600600	600*250	1500-2000	Front bale	18.5	7
YD-1600	160	1200800550	300*300	1500-2000	Turm over	18.5	7
YD-1600A	160	1600800800	350*350	1750-2250	Turn over	22	12
YD-2000	200	16001200800	350*400	2000-2500	Turn over	30	18
					side push
YD-2500	250	200012001000	450*450	2250-3500	Turn over	30	20
					Side push
YD3150	315	200014001200	450*500	3750-4500	Side push	37	32
YD4000	400	200016001200	500*500	4500-6250	Side push	45	40
YD-4000A	400	250016001200	600*500	7500-10000	Side push	45	50
