Aluminum Can Press Machine
This video is a test video of our baler. We have completed normal production and are doing the final inspection work.
Product Instruction
Hydraulic metal balers are highly versatile and come in different sizes and designs to suit various applications. They feature hydraulic systems that apply high-pressure force to compress metal materials into compact bales that are easy to handle and transport. The bales are then ready for shipment to recycling plants, where they can be processed and reused in the production of new metal products.
Machine Features
1. All models hydraulic baler machine are hydraulically driven and can be selected for manual operation or PLC automatic control.
2. There are bag delivery methods such as flip, side push, forward push, and manual take.
3. A variety of models are available: different pressures, bin sizes, and block sizes and shapes.
4. Hydraulic baler machine where there is no power source, a diesel engine can be used as power.
Product Parameters
|
Sr.no |
Type name |
unit |
Model or data |
||
|
Main cylinder |
Side cylinder |
Bale cylinder |
|||
|
1 |
Nominal pressure |
KN |
1372 |
357.8 |
285.1 |
|
2 |
Inner diameter of main cylinder |
mm |
φ250 |
φ160 |
φ110×2pcs |
|
3 |
Piston diameter |
mm |
φ180 |
φ105 |
φ70 |
|
4 |
stroke |
mm |
1700 |
1360 |
260 |
|
5 |
Max.pressure |
Mpa |
25 |
25 |
15 |
|
6 |
Bale density |
≥2.0 t/m3 （LIGHT AND THIN MATERIAL） |
|||
|
7 |
Electrical motor |
1pc |
18.5KW |
||
|
8 |
pump |
1pc |
80YCY14-1B |
||
|
9 |
Single cycle time |
s |
60（NO LOAD） |
||
|
10 |
Material box size |
mm |
1400×600×600 |
||
|
11 |
Bale size |
mm |
250×250×600 |
||
|
12 |
weight |
Kg |
ABOUT 7000 |
||
|
13 |
Bale |
|
FRONT BALE |
||
|
14 |
Operated by |
|
MANUAL FAST SPEED、INTERGRATION VALVE |
||
|
15 |
efficiency |
T |
1.75-2T/H |
||
|
16 |
Machine size |
mm |
4150×1450×1900（mm） |
||
Hydraulic metal balers are essential tools for the effective and efficient processing of scrap metal materials. They provide numerous benefits to the environment, the economy, and society as a whole. Investing in these machines is a wise decision for any business that values sustainability, efficiency, and profitability.
If you are insterested just feel free to send us email
