Shredder Machine

NVEQ-1600 series single-shaft shredders are suitable for the refinement of small and medium-sized materials and waste recycling in various industries. They mainly process high-hardness and high-toughness rubber materials, plastic products, wood, industrial waste paper, etc. The particle size after...

Send Inquiry

Chat Now

Shredder Machine Features

The blades are made of 9CrSi material. 9CrSi material is specifically designed for metal shredder blades, offering powerful crushing capabilities and extremely high crushing efficiency.

Low-speed reducer. Thanks to this reducer, the scrap metal shredder boasts high transmission efficiency, stable operation, and low noise.

High torque. This metal shredder is suitable for materials of various sizes, especially large and irregularly shaped waste.

Easy operation. Equipped with an independent power control cabinet, operation is simple.

Customization services are available. Depending on different needs, we can equip the machine with a frame, work platform, conveyor (for feeding or discharging), etc.

Shredder Machine Technical Data

Model	Unit	NVEB180	NVEB300	NVEB500
Motor	Kw	3	3	7.5
Blade Diameter And Hight	MM	D90*H8	D180*H12MM	D200*H20MM
Blade Number	Unit	22	24	25
Blade Material		9CRSI/SKD11
Output Capacity	KG	50-150	300-500	400-600
Output Size	CM	1-3	2-5	2-5
Weight	KG	450	530	600
Machine Dimensions	MM	8505001550	12005001550	10007001650
