Iron Shredder Machine

NVEQ-1600 series single-shaft shredders are suitable for the refinement of small and medium-sized materials and waste recycling in various industries. They mainly process high-hardness and high-toughness rubber materials, plastic products, wood, industrial waste paper, etc. The particle size after...

Send Inquiry

Chat Now

Iron Shredder Machine Introduction

The NVEQ series iron shredder machine effectively reduces material size through the combined action of crushing, tearing, and compressing forces. It is commonly used in municipal waste recycling plants for the pretreatment of scrap metal, especially scrap iron.

Iron Shredder Machine Features

Custom-designed for the required particle size.

Custom blades for optimal pulverization.

Modular design for easy and quick shaft replacement.

Equipped with a hydraulic discharge gate for handling materials that cannot be pulverized.

Easy-to-replace wear parts.

Quadruple sealing system effectively prevents leakage.

Iron Shredder Machine Technical Data

Model Name	NVEQ-1200
H.S. CODE	8479820090	Blade material	9crsi
Blade size(mm)	D400*T40	Output size	4-15cm
Blade Number	20	capacity	5000-8000KG/H
Shaft Number	2	Dimension (mm)	450020002400
Motor Number	2	Appx. N.W. (kg)	8000KG
Power(kw)	37*2
