Hydraulic Shearing Machine For Metal Steel

After shearing, the shearing machine should be able to ensure the straightness and parallelism of the shearing surface of the sheared plate, and minimize the distortion of the plate to obtain high-quality workpieces. The upper blade of the shearing machine is fixed on the knife holder, and the lower blade is fixed on the worktable. A material support ball is installed on the worktable, so that the sheet will not be scratched when sliding on it. The back gauge is used for sheet positioning, and the position is adjusted by the motor. The pressing cylinder is used to press the sheet to prevent the sheet from moving during shearing. Guardrails are safety devices to prevent workplace accidents. The return journey generally relies on nitrogen, which is fast and has a small impact.

Precautions during use

1. Start the shearing machine for several cycles of idling, to ensure that under normal conditions, try to cut sheets of different thicknesses, from thin to thick. Make sure the user is familiar with shearing machine performance.

2. Different blade gaps must be adjusted for different plate thicknesses during trial shearing. If the corresponding blade clearance is not adjusted, the blade durability will be affected.

3. Turn on the switch of the pressure gauge during the shearing process, observe the pressure value of the oil circuit, and the pressure should be less than 20MPa when cutting a 12mm plate. This remote pressure regulating valve No.9, the pressure is set at 20-22MPa when it leaves the factory, the user must abide by this regulation, and must not increase the pressure for shearing the surface of the material beyond the specified, causing damage to the machine.

4. The sound is balanced during operation. If the shearing machine is noisy, it should be stopped for inspection.

5. When the shearing machine is operating, the temperature of the fuel tank is raised to less than 60 degrees, and when it exceeds, it will be shut down and rested.
